12AWG 2C NMWU 300V 60C
Regular price $3.11 Save $-3.11Description
SUB-GROUND RESIDENTIAL CABLE 12AWG SOLID 2 CONDUCTORS COPPER NMWU FARMEX 300 VOLTS 60 ° CX 75 METERS CAB12 / 2W1075
Specifications
Mark | Approved Vendor | Item name | Non-metallic sheathed cable |
Cable dimensions | 12 | Number of driver | 2 |
Torronous and solid | Failed | Number of strands | 1 |
Length | 75 m | Driver material | Bare copper |
Insulation material | PVC | Nominal voltage | 300 VAC |
Outside diameter | 0.271 in x 0.542 in | Insulation thickness | 0.06 in |
Envelope thickness | 0.03 in | Nominal amperage | 25 A at 30 ° C ambient |
Nominal temperature | -25 to 60 ° C | Standards | CSA C22.2 n ° 48, fire resistance index FT1 |
Application | For exposed or concealed wiring in dry, damp or wet locations |
